Mkdocs Markdown¶

Pages are written in markdown Format and stored as *.md files within the doc folder. The Markdown implementation is nearly the same as used on GitHub but with some additions. Use mkdocs to convert it into static site.

To set an alternative title within the navigation define it at YAML at the top:

title: Test Page

# Test

...

Simple Formats¶

Structure the text using headings:

# Heading 1

## Heading 2

### Heading 3

Blockquotes are done using > signs:

> This is a block quote in which only the first line of the paragraph needs
> to be indented by `>` but it can also be done on each line.

This is a block quote in which only the first line of the paragraph needs to be indented by > but it can also be done on each line.

A horizontal line may be used to separate:

---

Use some inline text formatting:

Format	Example	Result
Italic	`_Italic_` or `Italic`	Italic
Bold	`__Bold__` or `Bold`	Bold
Superscript	`H^2^O`	H²O
Subscript	`CH~3~CH~2~OH`	CH₃CH₂OH
Insert	`^^Insert^^`	Insert
Delete	`~~Delete me~~`	~~Delete me~~
Mark	`==mark me==`	mark me
Emoji	`:smile:`
Code	`echo "Hello"`	`echo "Hello"`
Code + Highlighting	`:::bash echo "Hello"`	`echo "Hello"`
Keys	`++ctrl+alt+h++`	`Ctrl`+`Alt`+`H`
Link	`[Text](http://my-site.com)`	Text
Image	`![Logo](../logo.png)`

Find a list of all keys to be used within the ++ tags in the key map. But you can add more in the setup

Icons¶

The following icon sets are bundled with Material for MkDocs:

-   :material-account-circle: – `material/account-circle.svg`
-   :fontawesome-regular-laugh-wink: – `fontawesome/regular/laugh-wink.svg`
-   :octicons-repo-push-16: – `octicons/repo-push-16.svg`

– material/account-circle.svg
– fontawesome/regular/laugh-wink.svg
– octicons/repo-push-16.svg

HTML¶

It is also possible to add HTML tags directly. But this should be done only if there is no other way around.

Example

To add SVG images with links they have to be put into <object> tag:

<!--
To make this svg responsive add the following in svg:
preserveAspectRatio="xMinYMin meet" viewBox="0 0 {width} {height}"
-->
<object data="solutions.svg" type="image/svg+xml" width="100%">
![solutions overview](solutions.svg){: .center}
</object>

Lists¶

Unordered list:

-   water
-   cola
-   beer

water
cola
beer

Ordered list:

1. select
2. take
3. buy

select
take
buy

Definition List:

Type 1

: This is the explanation for the first paragraph.

Type 2

: This is the explanation for the second paragraph.

Type 1: This is the explanation for the first paragraph.
Type 2: This is the explanation for the second paragraph.

And finally a task list is also possible:

-   [x] item 1
    -   [x] item A
    -   [ ] item B
            more text
        -   [x] item a
        -   [ ] item b
        -   [x] item c
    -   [x] item C
-   [ ] item 2
-   [ ] item 3

Tables¶

Tables can have alignment:

| Left | Center | Right |
| :--- | :----: | ----: |
| one  |  two   | three |
| 1    |   2    |     3 |

Left	Center	Right
one	two	three
1	2	3

Block Messages¶

The Admonition extension configured above will allow to add text blocks.

!!! note

    Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod
    nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor
    massa, nec semper lorem quam in massa.

Note

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor massa, nec semper lorem quam in massa.

The different types will look like:

Note

Type: note, seealso

Abstract

Type: abstract, summary, tldr

Info

Type: info, todo

Tip

Type: tip, hint, important

Success

Type: success, check, done

Question

Type: question, help, faq

Warning

Type: warning, caution, attention

Failure

Type: failure, fail, missing

Danger

Type: danger, error

Bug

Type: bug

Example

Type: example, snippet

Quote

Type: quote, cite

The title can also be specified in double quotes behind the type or remove the title by setting "" for title:

!!! note "Individual"

Individual

The PyMarkdown.Details extension gives the same but as collapsible boxes:

??? note "Initially closed"

    Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod
    nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor
    massa, nec semper lorem quam in massa.

???+ note "Initially opened"

    Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod
    nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor
    massa, nec semper lorem quam in massa.

Initially closed

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor massa, nec semper lorem quam in massa.

Initially opened

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor massa, nec semper lorem quam in massa.

Tabs¶

Using Tabbed groups as tabs can be defined:

=== "Bash"

    ```bash
    #!/bin/bash

    echo "Hello world!"
    ```

=== "Explanation"

    This is only a short example of how to make tabs.

BashExplanation

#!/bin/bash

echo "Hello world!"

This is only a short example of how to make tabs.

If you have multiple blocks with the same tabs, their active state is shared using a script in extra.js.

Code Blocks¶

Highlight will help you in display code elements. You have multiple options to specify the language of a code block:

```sql
SELECT count(*) FROM my_table;
```

SELECT count(*) FROM my_table;

Or by indention and using a shebang:

    #!/bin/bash
    grep $1 $2

#!/bin/bash
grep $1 $2

Or by indention and three colon start line:

    :::bash
    grep $1 $2

:::bash
grep $1 $2

The kline umbers can be displayed:

```sql linenums="1"
SELECT *
FROM my_table;
```

1 2	`SELECT * FROM my_table;`

Using SuperFences specific lines can be highlighted by passing the line numbers to the hl_lines argument placed right after the language identifier.

```python hl_lines="3 4"
""" Bubble sort """
def bubble_sort(items):
    for i in range(len(items)):
        for j in range(len(items) - 1 - i):
            if items[j] > items[j + 1]:
                items[j], items[j + 1] = items[j + 1], items[j]
```

""" Bubble sort """
def bubble_sort(items):
    for i in range(len(items)):
        for j in range(len(items) - 1 - i):
            if items[j] > items[j + 1]:
                items[j], items[j + 1] = items[j + 1], items[j]

Add a title:

```python title="Bubble sort"
""" Bubble sort """
def bubble_sort(items):
    for i in range(len(items)):
        for j in range(len(items) - 1 - i):
            if items[j] > items[j + 1]:
                items[j], items[j + 1] = items[j + 1], items[j]
```

Bubble sort

""" Bubble sort """
def bubble_sort(items):
    for i in range(len(items)):
        for j in range(len(items) - 1 - i):
            if items[j] > items[j + 1]:
                items[j], items[j + 1] = items[j + 1], items[j]

Adding code annotations, which will be displayed bc click:

```yaml
theme:
    features:
        - content.code.annotate # (1)
```

1.  :man_raising_hand: I'm a code annotation! I can contain `code`, **formatted
    text**, images, ... basically anything that can be expressed in Markdown.

theme:
    features:
        - content.code.annotate # (1)

I'm a code annotation! I can contain code, formatted text, images, ... basically anything that can be expressed in Markdown.

Math¶

With the double dollar syntax math formulas can be added using the AsciiMath also MathML or LaTeX can be used.

It can be used inline within $...$ :

Formula: $p(x|y) = \frac{p(y|x)p(x)}{p(y)}$

Formula: $p(x|y) = \frac{p(y|x)p(x)}{p(y)}$

Or in a block within double $$ like in the following examples.

LatexAsciiMath

$$
x=\frac{-b \pm \sqrt{b^2 - 4ac}}{2a}
$$

\[ x=\frac{-b \pm \sqrt{b^2 - 4ac}}{2a} \]

$$
x=(-b +- sqrt(b^2 - 4ac))/(2a)
$$

\[ x=(-b +- sqrt(b^2 - 4ac))/(2a) \]

Some more examples in LaTeX are:

$$
\operatorname{ker} f=\{g\in G:f(g)=e_{H}\}{\mbox{.}}
$$

\[ \operatorname{ker} f=\{g\in G:f(g)=e_{H}\}{\mbox{.}} \]

A lot more is possible and as you see I prefer LaTeX because this is the most accurate and powerful syntax.

Attention

This will currently not be interpreted in PDF and printed in source format.

Progress Bar¶

With the ProgressBar plugin and some CSS styling already in the extra.css you can make progress bars:

[=0% "0%"]
[=5% "5%"]
[=25% "25%"]
[=45% "45%"]
[=65% "65%"]
[=85% "85%"]
[=100% "100% ready"]

[=50%]{: .thin}

25%

45%

65%

85%

100% ready

Diagrams¶

Warning

Diagrams may will not be accurate in PDF export. If this is necessary for you better make fixed graphics using yEd.

Using the blockdiag module graphics can be auto generated out of text representations. The syntax in all of them is the same, they have to be written in a block prefaced with the diagram name. Within the block there should be no empty lines.

Because prettier will remove indention and make it less readable a short comment  has to be added above such code blocks.

Attention

Keep in mind that if the diagrams use sub blocks with curly braces, they need to be weighted and unclosed curly braces will tend to an ParseException: no tokens left in the stream: <EOF> error.

Block Diagrams¶

Name the blocks and use arrows between them:

<!-- prettier-ignore -->
blockdiag {
   A -> B -> C -> D;
   A -> E -> F -> G;
}

Internal comments are also possible like shown in line 2. This will result in:

Note

If you need more precise or complexer diagrams consider using yEd to draw them and import it as SVG or PNG image.

Label Attributes

<!-- prettier-ignore -->
blockdiag {
   // Set labels to nodes.
   A [label = "foo"];
   B [label = "bar"];
   // And set text-color
   C [label = "baz"];

   // Set labels to edges. (short text only)
   A -> B [label = "click bar", textcolor="red"];
   B -> C [label = "click baz"];
   C -> A;
}

Style

You can style nodes and edges:

<!-- prettier-ignore -->
blockdiag {
   // Set boder-style, backgroun-color and text-color to nodes.
   A [style = dotted];
   B [style = dashed];
   C [color = pink, style = "3,3,3,3,15,3"]; //dashed_array format style
   D [color = "#888888", textcolor="#FFFFFF"];
   // Set border-style and color to edges.
   A -> B [style = dotted];
   B -> C [style = dashed];
   C -> D [color = "red", style = "3,3,3,3,15,3"]; //dashed_array format style
   // Set numbered-badge to nodes.
   E [numbered = 99];
   // Set arrow direction to edges.
   E -> F [dir = none];
   F -> G [dir = forward];
   G -> H [dir = back];
   H -> I [dir = both];
   // Set width and height to nodes.
   K [width = 192]; // default value is 128
   L [height = 64]; // default value is 40
   // Use thick line
   J -> K [thick]
   K -> L;
}

Note

Background images are not working within mkdocs at the moment.

Branches and Direction

<!-- prettier-ignore -->
blockdiag {
  // branching edges to multiple children
  A -> B, C;
  // branching edges from multiple parents
  D, E -> F;
}

Folding

<!-- prettier-ignore -->
blockdiag {
  A -> B -> C -> D -> E;
  // fold edge at C to D (D will be layouted at top level; left side)
  C -> D [folded];
}

Shapes

<!-- prettier-ignore -->
blockdiag {
  // standard node shapes
  box [shape = box];
  square [shape = square];
  roundedbox [shape = roundedbox];
  dots [shape = dots];
  circle [shape = circle];
  ellipse [shape = ellipse];
  diamond [shape = diamond];
  minidiamond [shape = minidiamond];
  note [shape = note];
  mail [shape = mail];
  cloud [shape = cloud];
  actor [shape = actor];
  beginpoint [shape = beginpoint];
  endpoint [shape = endpoint];
  box -> square -> roundedbox -> dots;
  circle -> ellipse -> diamond -> minidiamond;
  note -> mail -> cloud -> actor;
  beginpoint -> endpoint;
  // node shapes for flowcharts
  condition [shape = flowchart.condition];
  database [shape = flowchart.database];
  terminator [shape = flowchart.terminator];
  input [shape = flowchart.input];
  loopin [shape = flowchart.loopin];
  loopout [shape = flowchart.loopout];
  condition -> database -> terminator -> input;
  loopin -> loopout;
}

Stocked Shapes

<!-- prettier-ignore -->
blockdiag {
  // Set stacked to nodes.
  stacked [stacked];
  diamond [shape = "diamond", stacked];
  database [shape = "flowchart.database", stacked];

  stacked -> diamond -> database;
}

Dots Shape

<!-- prettier-ignore -->
blockdiag {
  A -> B, C, D;
  C [shape = "dots"];
  // hide edge forward to dots node
  A -> C [style = "none"];
}

blockdiag A -> B, C, D; C [shape = "dots"]; // hide edge forward to dots node A -> C [style = "none"]; }

Groups

<!-- prettier-ignore -->
blockdiag {
   A -> B -> C -> D;
   A -> E;
   A -> H;
   // A and B belong to first group.
   group {
      A; B;
   }
   // E, F and G belong to second group.
   group second_group {
      // Set group-label
      label = "second group";
      // Set background-color to this group.
      color = "#77FF77";
      // Set textcolor to this group
      textcolor = "#FF0000";
      E -> F -> G;
      // H and I belong to third "nested" group.
      group {
          label = "third group";
          color = "#FF0000";
          // Set group shape to 'line group' (default is box)
          shape = line;
          // Set line style (effects to 'line group' only)
          style = dashed;
          H -> I;
      }
   }
   // J belongs to second group
   J [group = second_group];
}

Fonts

<!-- prettier-ignore -->
blockdiag {
  // Set fontsize
  default_fontsize = 20;  // default value is 11
  A -> B [label = "large"];
  B -> C [label = "small", fontsize = 11];  // change fontsize of edge-label
  A [fontsize = 32];  // change fontsize of node-label
  group {
    label = "group label";
    fontsize = 16;  // change fontsize of group-label
    C;
  }
}

Attributes

<!-- prettier-ignore -->
blockdiag {
  // Set node metrix
  node_width = 200;  // default value is 128
  node_height = 100;  // default value is 40
  // Set span metrix
  span_width = 240;  // default value is 64
  span_height = 120;  // default value is 40
  // set default shape
  default_shape = roundedbox;  // default value is 'box'
  // set default colors
  default_node_color = lightblue;
  default_group_color = "#7777FF";
  default_linecolor = blue;
  default_textcolor = red;
  A -> B [label = "Use long long\nedge label"];
  A -> C;
  group {
    C;
  }
}

Classes

<!-- prettier-ignore -->
blockdiag {
  // Define class (list of attributes)
  class emphasis [color = pink, style = dashed];
  class redline [color = red, style = dotted];
  A -> B -> C;
  // Set class to nod
  A [class = "emphasis"];
  // Set class to edge
  A -> B [class = "redline"];
}

Portrait mode

<!-- prettier-ignore -->
blockdiag {
  orientation = portrait
  A -> B -> C;
       B -> D;
}

<!-- prettier-ignore -->
blockdiag {
  A -> B -> C;
  group {
    orientation = portrait
    C -> D -> E;
  }
}

Sequences¶

<!-- prettier-ignore -->
seqdiag {
    browser -> webserver [label = "GET /index.html"];
    browser <-- webserver;
    browser -> webserver [label = "POST /blog/comment"];
    webserver -> database [label = "INSERT comment"];
    webserver <-- database;
    browser <-- webserver;
    // self referenced edge
    A -> A [label = "self reference edge"];
}

Styling

<!-- prettier-ignore -->
seqdiag {
    // asynchronus edge
    A ->> B [label = "asynchronus edge"];
    B -->> C [label = "asynchronus dotted edge"];
    B <<-- C [label = "return asynchronus doted edge"];
    A <<- B [label = "return asynchronus edge"];
    // diagonal edge
    A -> B [diagonal, label = "diagonal edge"];
    A <- B [diagonal, label = "return diagonal edge"];
    // color of edge
    A -> B [label = "colored label", color = red];
}

Special Edges

<!-- prettier-ignore -->
seqdiag {
    // self referenced edge
    A -> A [label = "self reference edge"];
    // failed edge
    A -> B [label = "failed edge", failed];
    // auto return edge
    A => B [label = "call", return = "return"];
    // nested auto return edge
    A => B => C [label = "call", return = "return"];
}

Nested Sequences

<!-- prettier-ignore -->
seqdiag {
  // auto return edge
  A => B [label = "call", return = "return"];
  // nested auto return edge
  A => B => C [label = "call", return = "return"];
  // nested sequence
  A => B [label = "nested call"]{
     B => C [label = "call 1"];
     B => D [label = "call 2"];
     B => E [label = "call 3"];
  }
}

Separators

<!-- prettier-ignore -->
seqdiag {
  A -> B;
  // Separator
  === Separator line ===
  A -> B;
  // Delay separator
  ... Separator line ...
  A -> B;
}

Edge Notes

<!-- prettier-ignore -->
seqdiag {
  // Use note (put note on rightside)
  browser -> webserver [note = "request\nGET /"];
  browser <- webserver;
  // Use leftnote and rightnote
  browser -> webserver [leftnote = "send request"];
  browser <- webserver [rightnote = "send response"];
}

Attributes

<!-- prettier-ignore -->
seqdiag {
  // Set edge metrix.
  edge_length = 300;  // default value is 192
  span_height = 80;  // default value is 40
  // Set fontsize.
  default_fontsize = 16;  // default value is 11
  // Do not show activity line
  activation = none;
  // Numbering edges automaticaly
  autonumber = True;
  // Change note color
  default_note_color = lightblue;
  browser  -> webserver [label = "GET \n/index.html"];
  browser <-- webserver [note = "Apache works!"];
}

Ordering

<!-- prettier-ignore -->
seqdiag {
  // define order of elements
  // seqdiag sorts elements by order they appear
  browser; database; webserver;
  // diagram
  browser  -> webserver [label = "GET /index.html"];
  browser <-- webserver;
  browser  -> webserver [label = "POST /blog/comment"];
              webserver  -> database [label = "INSERT comment"];
              webserver <-- database;
  browser <-- webserver;
}

Activity¶

<!-- prettier-ignore -->
actdiag {
    write -> convert -> image
    lane user {
        label = "User"
        write [label = "Writing reST"];
        image [label = "Get diagram IMAGE"];
    }
    lane actdiag {
        convert [label = "Convert reST to Image"];
    }
}

Network¶

<!-- prettier-ignore -->
nwdiag {
  network dmz {
      address = "210.x.x.x/24"
      web01 [address = "210.x.x.1"];
      web02 [address = "210.x.x.2"];
  }
  network internal {
      address = "172.x.x.x/24";
      web01 [address = "172.x.x.1"];
      web02 [address = "172.x.x.2"];
      db01;
      db02;
  }
}

Multiple Addresses

<!-- prettier-ignore -->
nwdiag {
  network dmz {
      address = "210.x.x.x/24"
      // set multiple addresses (using comma)
      web01 [address = "210.x.x.1, 210.x.x.20"];
      web02 [address = "210.x.x.2"];
  }
  network internal {
      address = "172.x.x.x/24";
      web01 [address = "172.x.x.1"];
      web02 [address = "172.x.x.2"];
      db01;
      db02;
  }
}

Grouping

<!-- prettier-ignore -->
nwdiag {
  network Sample_front {
    address = "192.168.10.0/24";
    // define group
    group web {
      web01 [address = ".1"];
      web02 [address = ".2"];
    }
  }
  network Sample_back {
    address = "192.168.20.0/24";
    web01 [address = ".1"];
    web02 [address = ".2"];
    db01 [address = ".101"];
    db02 [address = ".102"];
    // define network using defined nodes
    group db {
      db01;
      db02;
    }
  }
}

Peer Networks

<!-- prettier-ignore -->
nwdiag {
  inet [shape = cloud];
  inet -- router;
  network {
    router;
    web01;
    web02;
  }
}

Rack¶

<!-- prettier-ignore -->
rackdiag {
  // define height of rack
  16U;

  // define rack items
  1: UPS [2U];
  3: DB Server
  4: Web Server
  5: Web Server
  6: Web Server
  7: Load Balancer
  8: L3 Switch
}

Attributes

<!-- prettier-ignore -->
rackdiag {
  // Change order of rack-number as ascending
  ascending;
  // define height of rack
  12U;
  // define description of rack
  description = "Tokyo/1234 East";
  // define rack units
  1: UPS [2U];   // define height of unit
  3: DB Server [5kg]  // define weight of unit
  4: Web Server [0.5A]  // define ampere of unit
  5: Web Server
  6: Web Server
  7: Load Balancer
  8: L3 Switch
}

Units in Same Level

<!-- prettier-ignore -->
rackdiag {
  // define height of rack
  16U;
  // define rack items
  1: UPS [2U];
  3: DB Server
  4: Web Server 1  // put 2 units to rack-level 4
  4: Web Server 2
  5: Web Server 3
  5: Web Server 4
  7: Load Balancer
  8: L3 Switch
}

Multiple Racks

<!-- prettier-ignore -->
rackdiag {
  // define 1st rack
  rack {
    16U;
    // define rack items
    1: UPS [2U];
    3: DB Server
    4: Web Server
    5: Web Server
    6: Web Server
    7: Load Balancer
    8: L3 Switch
  }
  // define 2nd rack
  rack {
    12U;
    // define rack items
    1: UPS [2U];
    3: DB Server
    4: Web Server
    5: Web Server
    6: Web Server
    7: Load Balancer
    8: L3 Switch
  }
}

Unavailable Units

<!-- prettier-ignore -->
rackdiag {
  12U;
  1: Server
  2: Server
  3: Server
  4: Server
  5: N/A [8U];
}

Packet¶

<!-- prettier-ignore -->
packetdiag {
  colwidth = 32
  node_height = 72
  0-15: Source Port
  16-31: Destination Port
  32-63: Sequence Number
  64-95: Acknowledgment Number
  96-99: Data Offset
  100-105: Reserved
  106: URG [rotate = 270]
  107: ACK [rotate = 270]
  108: PSH [rotate = 270]
  109: RST [rotate = 270]
  110: SYN [rotate = 270]
  111: FIN [rotate = 270]
  112-127: Window
  128-143: Checksum
  144-159: Urgent Pointer
  160-191: (Options and Padding)
  192-223: data [colheight = 3]
}

Charts¶

Warning

While charts are dynamically created using JavaScript they can not be exported into PDF. If this is necessary for you better add them as fixed graphic files.

As HTML in markdown is possible this can be done using external libraries like Chart.js.

<canvas id="myChart" width="400" height="400"></canvas>

<script src="https://cdn.jsdelivr.net/npm/chart.js@3.6.0/dist/chart.min.js"></script>
<script>
const ctx = document.getElementById('myChart').getContext('2d');
const myChart = new Chart(ctx, {
    type: 'bar',
    data: {
        labels: ['Red', 'Blue', 'Yellow', 'Green', 'Purple', 'Orange'],
        datasets: [{
            label: '# of Votes',
            data: [12, 19, 3, 5, 2, 3],
            backgroundColor: [
                'rgba(255, 99, 132, 0.2)',
                'rgba(54, 162, 235, 0.2)',
                'rgba(255, 206, 86, 0.2)',
                'rgba(75, 192, 192, 0.2)',
                'rgba(153, 102, 255, 0.2)',
                'rgba(255, 159, 64, 0.2)'
            ],
            borderColor: [
                'rgba(255, 99, 132, 1)',
                'rgba(54, 162, 235, 1)',
                'rgba(255, 206, 86, 1)',
                'rgba(75, 192, 192, 1)',
                'rgba(153, 102, 255, 1)',
                'rgba(255, 159, 64, 1)'
            ],
            borderWidth: 1
        }]
    },
    options: {
        scales: {
            y: {
                beginAtZero: true
            }
        }
    }
});
</script>

Abbreviations¶

Abbreviations (from the extra package) are defined as an extra paragraph mostly at the end of the document:

The HTML specification
is maintained by the W3C.

*[HTML]: Hyper Text Markup Language
*[W3C]: World Wide Web Consortium

This will be rendered with a tooltip on each occurrence of this words:

The HTML specification is maintained by the W3C.

Combined with the later described includes it is also possible to place all abbreviations in a single file and include it at the end of each page.

Footnotes¶

The Footnote syntax follows the generally accepted syntax of the Markdown community. You add the footnote using [^1] with the correct number and define the content of this footnote later:

Footnotes[^1] have a label[^@#$%] and the footnote's content.

[^1]: This is a footnote content.
[^@#$%]: A footnote on the label: "@#\$%".

This will look like:

Footnotes¹ have a label² and the footnote's content.

A footnote label must start with a caret ^ and may contain any inline text (including spaces) between a set of square brackets []. Only the first caret has any special meaning.

A footnote content must start with the label followed by a colon and at least one space. The label used to define the content must exactly match the label used in the body (including capitalization and white space). The content would then follow the label either on the same line or on the next line. The content may contain multiple lines, paragraphs, code blocks, blockquotes and most any other markdown syntax. The additional lines must be indented one level (four spaces or one tab).

[^1]: The first paragraph of the definition.

    Paragraph two of the definition.

    > A blockquote with
    > multiple lines.

        a code block

    A final paragraph.

Include¶

It is possible to include other markdown or files with three possible statements. The statement will be replaced by the contents of the given file.

Include relative text
```
{ % include "../test.yml" %}
```
No space before first percent sign to work!
Include relative markdown
```
{ % include-markdown "../README.md" %}
```
No space before first percent sign to work!

The include extension will work recursively, so any included files within will also be included. This replacement is done prior to any other Markdown processing, so any Markdown syntax that you want can be used within your included files.
Include absolute markdown
```
{ !docs/test.yml!}
```
No space before first exclamation mark to work!

The include extension will work recursively, so any included files within will also be included. This replacement is done prior to any other Markdown processing, so any Markdown syntax that you want can be used within your included files.

Attention

This method will not preserve indention and therefore is not possible in any blocks.

Also the first two solutions supports to specify which part of the file to insert:

{ % include "../test.html"
   start="<!--intro-start-->"
   end="<!--intro-end-->"
%}

Attributes¶

Using attributes it is possible to set the various HTML element's attributes for output. An example attribute list might look like this:

{: #someid .someclass somekey='some value' }

This shows the possible definitions:

A word which starts with # will set the id of an element.
A word which starts with . will be added to the list of classes assigned to an element.
A key/value pair somekey='some value' will assign that pair to the element.

This can be set on block level elements if defined on the last line of the block by itself.

This is a paragraph.
{: #an_id .a_class }

The one exception is headers, as they are only ever allowed on one line. So there you neet to write:

### A hash style header ### {: #hash }

If used on inline elements the attributes are defined immediately after the element without any separation:

[link](http://example.com){: class="foo bar" title="Some title!" }

Examples¶

Display Link as Button:

[Button](#top){: .md-button}

Button

Left/right align with text float on the right:

Text
![Example](../assets/alinex-logo.png){: .left }
![Example](../assets/alinex-logo.png){: .right }

Text

Set image size to 25% of width:

![Example](../assets/gray-books.png){: .icon }

Add drop shadow:

![Example](../assets/default.jpg){: .icon .border }

Add image zoom:

![Example](../assets/default.jpg){: .icon .zoom }
![Example](../assets/default.jpg){: .icon .zoom2 }

You may define more such classes in the additional CSS file.

This is a footnote content. ↩
A footnote on the label: "@#$%". ↩

Last update: December 13, 2021

Mkdocs Markdown¶

Navigation title¶

Simple Formats¶

Icons¶

HTML¶

Lists¶

Tables¶

Block Messages¶

Tabs¶

Code Blocks¶

Math¶

Progress Bar¶

Diagrams¶

Block Diagrams¶

Sequences¶

Activity¶

Network¶

Rack¶

Packet¶

Charts¶

Abbreviations¶

Footnotes¶

Include¶

Attributes¶

Examples¶
